| CPU | Support VIA Nano L2007 (65nm, 1.6GHz)processor
Front Side Bus 800MHz |
| Chipset | VIA VX900H Chipsets
VIA Chrome9 HD DX9 3D engines ( Share System Memory: 64/128/256/512MB) |
| Memory | 2 * 240-pin DIMM Sockets for un-buffered DDR3 1066MHz SDRAM up to 8GB |
| Expansion Slots | 1 * PCIe x 16 slot (x 8 card) |
| Power Management | ACPI S3/S4 Compliant ,supports VIA PowerSaver™ feature |
| Storage | 2 * Serial ATA2 3Gb/s connectors with RAID 0,1 function
1 * Mini PCI-E |
| Audio | VIA VT1705 HD Audio Code with 6-Channel |
| Ethernet LAN | 1 * RTL8111E 10 / 100 / 1000 PCI-E LAN |
| USB | Embedded 7 * USB 2.0/1.1 |
| LVDS | Each of onboard 24-bit Dual & Single channel LVDS connector |
| Rear Panel I / O | 4 * USB 2.0/1.1 ports
1 * RJ-45 port & 1 * SPDIF out
3 * Audio I/O ports ( Line-in, Mic and Line-out )
1 * VGA port
1 * DB-9 RS232 COM port
1 * HDMI Connector |
| Internal I / O | 1 * CPU Smart Fan Connector, 2 * Sys/Chassis Fan Connectors
2 * USB 2.0/1.1 headers for 3 USB ports
1 * 9-Pin COM Port header (RS232/422/485)
1 * 24 bit Dual Channel & 1 * 24 bit Single Channel LVDS header
1 * Parallel header
1 * GPIO header
1 * 24-pin ATX power connector |
| BIOS | AMI 8MB DIP-SPI Flash ROM |
| Form Factor | Mini-ITX Embedded Motherboard(170mmx170mm) |
| Packing | Color Box Dimension:200(W) x 200(D) x 70(H)mm
20 PCS in Cases Gross Weight :15.4KGS
20 PCS Net Weight:10.3KGS
20 PCS / Cases, Case size : 720(L) x 410(W) x 200(H)mm |
| Certificate | CE,FCC,RoHS |
| Functional | ATM, Automation, medical Equipment, Security, Networking, POS, General Application, Gaming Machine, Transportation |
| Temperature | Operating within 0~60 centigrade
Storage within -20-85 centigrade |
